LEWATIT® MonoPlus TP 209 XL

High-capacity monodisperse iminodiacetic chelating resin with large 0.84 mm beads for base-metal recovery in RIP.
On this Page

Product Description

Lewatit® MonoPlus TP 209 XL is a weakly acidic, macroporous cation exchange resin with chelating iminodiacetate (IDA) groups for the selective extraction of heavy metal cations from weakly acidic to weakly basic solutions. With its big bead size as well as the high operational capacity this resin is tailor-made for the concentration, extraction and recovery of base metals in Resin-in-Pulp (RIP) processes.
Cations are removed from neutralized waters in the following order: Fe3+ > Cu2+ > VO2+ > UO2 2+ > Pb2+ > Ni2+ > Zn2+ > Cd2+ > Fe2+ > Mn2+ > Ca2+ > Mg2+ >> Na+.


Lewatit® MonoPlus TP 209 XL has a monodisperse bead size distribution, i.e. beads of uniform size.

Its high degree of cross-linkage results in an improved resistance towards mechanical stress such as abrasion and attrition.

Compared with the standard grade IDA resin Lewatit® MonoPlusTP 207 offers the following advantages:

  • Lower dynamic pressure drop at the same flow rate

  • Diminished risk of accumulation of suspended solids

  • Easier screening and sieving during resin/feed separation

Brand

LEWATIT®

Product Type

Ion Exchange Resin

Material number

57546577

Removal of cations

Heavy metal removal

Purification of chemical solutions

Refining of battery materials

Recovery of battery materials

Waste water treatment
